PDF image disappears when opening a saved file in MeasureSquare 2015
In this article, we will show you how to bring the disappeared image back in MeasureSquare 2015
This article applies to all versions of MeasureSquare 2015
Method 1:
Method 2:
Use an administrator account to log on to Windows 10.
From the desktop screen, right-click the Start button to open its context menu.
Click System
.
From the left pane of the System window, click Advanced system settings.
On the System Properties box, ensure that you are on the Advanced tab.
Click the Settings button from under the Performance section.

On the Performance Options box, go to the Advanced tab.
Click the Change button from under the Virtual memory section.

On the Virtual Memory box, uncheck the Automatically manage paging file size for all drives checkbox.
From the available list, click to select the drive on which Windows 10 is installed. (C: in most cases.)
From below the list, click to select the Custom size radio button.
In the now-enabled fields, type the minimum and maximum size of the Pagefile in megabytes (MB). For example, find the recommended memory in the windows below. Use it as the initial size. Add 500M to the initial size as " maximum size"
.
Click Set and then click OK
Restart your computer when done.
Re-start MeasureSquare
Once back in Measure Square, copy and paste or import your pdf to current tab
then, scale image so it aligns with take off (if you have more than one PDF repeat the steps for each page
